EGPA800ELL561ML30S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 560UF 20% 80V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EGPA800ELL561ML30S Datasheet
-
ECAD Model
- Share
In Stock: 659
Can ship immediately
Pricing:
- 1$3.65
- 10$2.95216
- 100$2.25464
- 500$1.71778
- 1,000$1.50306
- 2,500$1.44938
- 5,000$1.3957
Quote It
Technical Details
- Series:GPA
- Package:Bulk
- Part Status:Active
- Capacitance:560 µF
- Tolerance:±20%
- Voltage - Rated:80 V
- ESR (Equivalent Series Resistance):53mOhm @ 100kHz
- Lifetime @ Temp.:5000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:1.165 A @ 120 Hz
- Ripple Current @ High Frequency:2.33 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.240" (31.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
