LGL2W271MELA40
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 270UF 20% 450V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet LGL2W271MELA40 Datasheet
-
ECAD Model
- Share
In Stock: 264
Can ship immediately
Pricing:
- 1$7.35
- 10$6.53748
- 100$5.22971
- 500$4.49426
- 1,000$4.44524
Quote It
Technical Details
- Series:LGL
- Package:Bulk
- Part Status:Active
- Capacitance:270 µF
- Tolerance:±20%
- Voltage - Rated:450 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:930 mA @ 120 Hz
- Ripple Current @ High Frequency:1.3299 A @ 50 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.984" Dia (25.00mm)
- Height - Seated (Max):1.654" (42.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
