ALF70C562DF100
KEMET
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 5600UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 216
Can ship immediately
Pricing:
- 1$9.07
Quote It
Technical Details
- Series:ALF70
- Package:Bulk
- Part Status:Active
- Capacitance:5600 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):51mOhm @ 100Hz
- Lifetime @ Temp.:15000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:6.77 A @ 100 Hz
- Ripple Current @ High Frequency:8.76 A @ 10 kHz
- Impedance:41 mOhms
- Lead Spacing:0.886" (22.50mm)
- Size / Dimension:1.378" Dia (35.00mm)
- Height - Seated (Max):2.047" (52.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In - 4 Lead
