B43505C9337M000

TDK EPCOS
In Stock: 219

Can ship immediately

Pricing:
  • 1$11.89
  • 10$11.29655
  • 100$8.91813
  • 500$7.90742
  • 1,000$7.43178

Quote It

Technical Details

  • Series:B43505
  • Package:Bulk
  • Part Status:Not For New Designs
  • Capacitance:330 µF
  • Tolerance:±20%
  • Voltage - Rated:400 V
  • ESR (Equivalent Series Resistance):270mOhm @ 100Hz
  • Lifetime @ Temp.:5000 Hrs @ 105°C
  • Operating Temperature:-40°C ~ 105°C
  • Polarization:Polar
  • Ratings:-



  • Applications:General Purpose
  • Ripple Current @ Low Frequency:1.7 A @ 100 Hz
  • Ripple Current @ High Frequency:-
  • Impedance:330 mOhms
  • Lead Spacing:0.394" (10.00mm)
  • Size / Dimension:1.378" Dia (35.00mm)
  • Height - Seated (Max):1.654" (42.00mm)
  • Surface Mount Land Size:-
  • Mounting Type:Through Hole
  • Package / Case:Radial, Can - Snap-In

Related Products


25USG47000MEFCSN35X50

CAP ALUM 47000UF 20% 25V SNAP

25USG47000MEFCSN35X50 Datasheet
  • 1: $12.01000
  • 10: $11.40530
  • 100: $9.00393

80MXG4700MEFCSN30X35

CAP ALUM 4700UF 20% 80V SNAP

80MXG4700MEFCSN30X35 Datasheet
  • 1: $12.06000
  • 10: $11.45438
  • 100: $9.04280

LAQ2G471MELC45

CAP ALUM 470UF 20% 400V SNAP

LAQ2G471MELC45 Datasheet
  • 1: $12.27000
  • 10: $11.65493
  • 100: $9.20156

LGR2W331MELC50
