B41580A9688M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 6800UF 20% 100V SCREW
- CategoryAluminum Electrolytic Capacitors
- Datasheet B41580A9688M000 Datasheet
-
ECAD Model
- Share
In Stock: 202
Can ship immediately
Pricing:
- 1$23.34
- 10$22.11158
- 100$17.81211
- 500$15.96947
Quote It
Technical Details
- Series:B41580
- Package:Bulk
- Part Status:Active
- Capacitance:6800 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):24mOhm @ 100Hz
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:8.7 A @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:25 mOhms
- Lead Spacing:0.874" (22.20mm)
- Size / Dimension:2.032" Dia (51.60mm)
- Height - Seated (Max):3.217" (81.70mm)
- Surface Mount Land Size:-
- Mounting Type:Chassis Mount
- Package / Case:Radial, Can - Screw Terminals
