580LSU2200MNB64X149
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2200UF 20% 580V SCREW
- CategoryAluminum Electrolytic Capacitors
- Datasheet 580LSU2200MNB64X149 Datasheet
-
ECAD Model
- Share
In Stock: 210
Can ship immediately
Pricing:
- 1$93.61
- 10$87.75924
- 100$79.56829
Quote It
Technical Details
- Series:LSU
- Package:Bulk
- Part Status:Active
- Capacitance:2200 µF
- Tolerance:±20%
- Voltage - Rated:580 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 85°C
- Operating Temperature:-25°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:7.1 A @ 120 Hz
- Ripple Current @ High Frequency:9.23 A @ 10 kHz
- Impedance:-
- Lead Spacing:1.110" (28.20mm)
- Size / Dimension:2.520" Dia (64.00mm)
- Height - Seated (Max):5.984" (152.00mm)
- Surface Mount Land Size:-
- Mounting Type:Chassis Mount
- Package / Case:Radial, Can - Screw Terminals
