LNR1E684MSE
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 680000UF 20% 25V SCREW
- CategoryAluminum Electrolytic Capacitors
- Datasheet LNR1E684MSE Datasheet
-
ECAD Model
- Share
In Stock: 152
Can ship immediately
Pricing:
- 1$150.66
- 10$149.01155
Quote It
Technical Details
- Series:LNR
- Package:Bulk
- Part Status:Active
- Capacitance:680000 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:33.3 A @ 120 Hz
- Ripple Current @ High Frequency:-
- Impedance:-
- Lead Spacing:1.252" (31.80mm)
- Size / Dimension:3.543" Dia (90.00mm)
- Height - Seated (Max):8.780" (223.00mm)
- Surface Mount Land Size:-
- Mounting Type:Chassis Mount
- Package / Case:Radial, Can - Screw Terminals
