B43458A5129M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 12000UF 20% 450V SCREW
- CategoryAluminum Electrolytic Capacitors
- Datasheet B43458A5129M000 Datasheet
-
ECAD Model
- Share
In Stock: 130
Can ship immediately
Pricing:
- 1$303.39
- 10$293.459
Quote It
Technical Details
- Series:B43458
- Package:Bulk
- Part Status:Not For New Designs
- Capacitance:12000 µF
- Tolerance:±20%
- Voltage - Rated:450 V
- ESR (Equivalent Series Resistance):9mOhm @ 100Hz
- Lifetime @ Temp.:12000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:32 A @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:12 mOhms
- Lead Spacing:1.248" (31.70mm)
- Size / Dimension:3.583" Dia (91.00mm)
- Height - Seated (Max):8.740" (222.00mm)
- Surface Mount Land Size:-
- Mounting Type:Chassis Mount
- Package / Case:Radial, Can - Screw Terminals
