B43727A9228M600
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2200UF 20% 400V SCREW
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 192
Can ship immediately
Pricing:
- 1$31.92
Quote It
Technical Details
- Series:B43727
- Package:Bulk
- Part Status:Active
- Capacitance:2200 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):55mOhm @ 100Hz
- Lifetime @ Temp.:12000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:7.65 A @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:85 mOhms
- Lead Spacing:0.874" (22.20mm)
- Size / Dimension:2.031" Dia (51.60mm)
- Height - Seated (Max):3.217" (81.70mm)
- Surface Mount Land Size:-
- Mounting Type:Chassis, Stud Mount
- Package / Case:Radial, Can - Screw Terminals
