860010272006
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP 120 UF 20% 10 V
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 400
Can ship immediately
Pricing:
- 1$0.12
- 2,000$0.06987
Quote It
Technical Details
- Series:WCAP-ATG8
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:120 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:209 mA @ 120 Hz
- Ripple Current @ High Frequency:288.42 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.079" (2.00mm)
- Size / Dimension:0.197" Dia (5.00mm)
- Height - Seated (Max):0.492" (12.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
