EEU-EB1J100SB
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 10UF 20% 63V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-EB1J100SB Datasheet
-
ECAD Model
- Share
In Stock: 795
Can ship immediately
Pricing:
- 1$0.33
- 2,000$0.06962
- 4,000$0.0644
- 10,000$0.06092
- 14,000$0.05778
- 50,000$0.05221
- 100,000$0.04613
Quote It
Technical Details
- Series:EB
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:10 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:30 mA @ 120 Hz
- Ripple Current @ High Frequency:49.5 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.197" Dia (5.00mm)
- Height - Seated (Max):0.472" (12.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
