860080474011
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 270UF 20% 25V THRU HOLE
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 520
Can ship immediately
Pricing:
- 1$0.34
- 800$0.20895
- 1,600$0.19994
Quote It
Technical Details
- Series:WCAP-ATLI
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:270 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:-
- Ripple Current @ High Frequency:850 mA @ 100 kHz
- Impedance:63 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.689" (17.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
