UWR0J221MCL1GB
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 6.3V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UWR0J221MCL1GB Datasheet
-
ECAD Model
- Share
In Stock: 859
Can ship immediately
Pricing:
- 1$0.35
- 1,000$0.08443
- 2,000$0.07999
- 5,000$0.07555
- 10,000$0.0711
- 25,000$0.06666
- 50,000$0.06222
- 100,000$0.05777
Quote It
Technical Details
- Series:UWR
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:110 mA @ 120 Hz
- Ripple Current @ High Frequency:165 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.217" (5.50mm)
- Surface Mount Land Size:0.260" L x 0.260" W (6.60mm x 6.60mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
