UCB1VR33MCL1GS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 0.33UF 20% 35V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCB1VR33MCL1GS Datasheet
-
ECAD Model
- Share
In Stock: 375
Can ship immediately
Pricing:
- 1$0.42
- 1,500$0.10537
- 3,000$0.09982
- 4,500$0.09427
- 10,500$0.08872
- 15,000$0.08595
- 37,500$0.08318
- 75,000$0.07764
Quote It
Technical Details
- Series:UCB
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Not For New Designs
- Capacitance:0.33 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:7000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:3.2 mA @ 120 Hz
- Ripple Current @ High Frequency:4.8 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.157" Dia (4.00mm)
- Height - Seated (Max):0.276" (7.00mm)
- Surface Mount Land Size:0.169" L x 0.169" W (4.30mm x 4.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
