865080249010
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP 220 UF 20% 10 V
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 388
Can ship immediately
Pricing:
- 1$0.46
- 1,000$0.27415
Quote It
Technical Details
- Series:WCAP-ASLI
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:185.25 mA @ 120 Hz
- Ripple Current @ High Frequency:285 mA @ 100 kHz
- Impedance:400 mOhms
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.256" (6.50mm)
- Surface Mount Land Size:0.327" L x 0.327" W (8.30mm x 8.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
