25SEV4.7M4X5.5
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 4.7UF 20% 25V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet 25SEV4.7M4X5.5 Datasheet
-
ECAD Model
- Share
In Stock: 736
Can ship immediately
Pricing:
- 1$0.47
- 2,000$0.10566
- 4,000$0.09979
- 10,000$0.09392
- 14,000$0.09098
- 50,000$0.08218
- 100,000$0.07631
Quote It
Technical Details
- Series:SEV
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:4.7 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:18 mA @ 120 Hz
- Ripple Current @ High Frequency:27 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.157" Dia (4.00mm)
- Height - Seated (Max):0.217" (5.50mm)
- Surface Mount Land Size:0.169" L x 0.169" W (4.30mm x 4.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
