UMW1A470MDD1TP
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 47UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UMW1A470MDD1TP Datasheet
-
ECAD Model
- Share
In Stock: 291
Can ship immediately
Pricing:
- 1$0.47
- 2,000$0.09663
- 4,000$0.09126
- 10,000$0.0859
- 14,000$0.08321
- 50,000$0.07516
- 100,000$0.06979
Quote It
Technical Details
- Series:UMW
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:47 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:Audio
- Ripple Current @ Low Frequency:52 mA @ 120 Hz
- Ripple Current @ High Frequency:78 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.098" (2.50mm)
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.236" (6.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
