UWT1C151MCL1GS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 150UF 20% 16V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UWT1C151MCL1GS Datasheet
-
ECAD Model
- Share
In Stock: 727
Can ship immediately
Pricing:
- 1$0.49
- 900$0.11197
- 1,800$0.10637
- 2,700$0.10077
- 4,500$0.09517
- 9,000$0.08958
- 22,500$0.08678
- 45,000$0.08398
- 90,000$0.07838
Quote It
Technical Details
- Series:UWT
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:150 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:95 mA @ 120 Hz
- Ripple Current @ High Frequency:142.5 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.303" (7.70mm)
- Surface Mount Land Size:0.260" L x 0.260" W (6.60mm x 6.60mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
