860160374026
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP 560 UF 20% 16 V
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 956
Can ship immediately
Pricing:
- 1$0.5
- 800$0.30966
- 1,600$0.29666
Quote It
Technical Details
- Series:WCAP-ATLL
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:560 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:4000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:501.12 mA @ 120 Hz
- Ripple Current @ High Frequency:864 mA @ 100 kHz
- Impedance:260 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.689" (17.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
