ESC477M025AH2EA
KEMET
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 20% 25V THRUHOLE
- CategoryAluminum Electrolytic Capacitors
- Datasheet ESC477M025AH2EA Datasheet
-
ECAD Model
- Share
In Stock: 739
Can ship immediately
Pricing:
- 1$0.5
- 700$0.15626
- 1,400$0.13438
- 2,100$0.12812
- 4,900$0.12188
- 17,500$0.1125
- 35,000$0.10938
- 70,000$0.10313
Quote It
Technical Details
- Series:ESC
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):640mOhm @ 100kHz
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:945 mA @ 120 Hz
- Ripple Current @ High Frequency:1.05 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.669" (17.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
