EEE-1EA100NP
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 10UF 20% 25V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEE-1EA100NP Datasheet
-
ECAD Model
- Share
In Stock: 493
Can ship immediately
Pricing:
- 1$0.52
- 1,000$0.1239
- 2,000$0.11737
- 5,000$0.11085
- 10,000$0.10433
- 25,000$0.09781
- 50,000$0.09129
- 100,000$0.08477
Quote It
Technical Details
- Series:S
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:10 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Bi-Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:28 mA @ 120 Hz
- Ripple Current @ High Frequency:47.6 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.213" (5.40mm)
- Surface Mount Land Size:0.260" L x 0.260" W (6.60mm x 6.60mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
