EEU-FR1V221B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 35V RADIAL TH
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 567
Can ship immediately
Pricing:
- 1$0.53
- 1,000$0.1408
- 2,000$0.13252
- 5,000$0.12424
- 10,000$0.11596
- 25,000$0.11264
Quote It
Technical Details
- Series:FR
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:6000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:665 mA @ 120 Hz
- Ripple Current @ High Frequency:950 mA @ 100 kHz
- Impedance:56 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.512" (13.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
