UWG1V220MCL1GB
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 22UF 20% 35V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UWG1V220MCL1GB Datasheet
-
ECAD Model
- Share
In Stock: 670
Can ship immediately
Pricing:
- 1$0.54
- 1,000$0.11681
- 2,000$0.11066
- 5,000$0.10451
- 10,000$0.09836
- 25,000$0.09222
- 50,000$0.08607
- 100,000$0.07992
Quote It
Technical Details
- Series:UWG
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:22 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:-
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:70 mA @ 120 Hz
- Ripple Current @ High Frequency:140 mA @ 100 kHz
- Impedance:1 Ohms
- Lead Spacing:-
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.213" (5.40mm)
- Surface Mount Land Size:0.260" L x 0.260" W (6.60mm x 6.60mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
