UCW1V330MCL1GS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 33UF 20% 35V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCW1V330MCL1GS Datasheet
-
ECAD Model
- Share
In Stock: 927
Can ship immediately
Pricing:
- 1$0.56
- 800$0.15938
- 1,600$0.15052
- 2,400$0.14167
- 4,000$0.13282
- 8,000$0.12396
- 20,000$0.12175
- 40,000$0.12042
Quote It
Technical Details
- Series:UCW
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:33 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:7000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:115 mA @ 120 Hz
- Ripple Current @ High Frequency:230 mA @ 100 kHz
- Impedance:1 Ohms
- Lead Spacing:-
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.343" (8.70mm)
- Surface Mount Land Size:0.260" L x 0.260" W (6.60mm x 6.60mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
