UPW0J821MPD6TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 820UF 20% 6.3V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPW0J821MPD6TD Datasheet
-
ECAD Model
- Share
In Stock: 326
Can ship immediately
Pricing:
- 1$0.57
- 500$0.18008
- 1,000$0.15307
- 2,500$0.14406
- 5,000$0.13506
- 12,500$0.12381
- 25,000$0.12156
- 50,000$0.11705
Quote It
Technical Details
- Series:UPW
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:820 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:566.25 mA @ 120 Hz
- Ripple Current @ High Frequency:755 mA @ 100 kHz
- Impedance:90 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
