EEE-1CA221P
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 16V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEE-1CA221P Datasheet
-
ECAD Model
- Share
In Stock: 314
Can ship immediately
Pricing:
- 1$0.59
- 500$0.18342
- 1,000$0.1559
- 2,500$0.14673
- 5,000$0.13756
- 12,500$0.12609
- 25,000$0.12473
Quote It
Technical Details
- Series:S
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:280 mA @ 120 Hz
- Ripple Current @ High Frequency:476 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.402" (10.20mm)
- Surface Mount Land Size:0.327" L x 0.327" W (8.30mm x 8.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
