UPV1E121MGD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 120UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPV1E121MGD1TD Datasheet
-
ECAD Model
- Share
In Stock: 1,063
Can ship immediately
Pricing:
- 1$0.62
- 1,000$0.14988
- 2,000$0.14107
- 5,000$0.13225
- 10,000$0.12343
- 25,000$0.11903
- 50,000$0.11462
Quote It
Technical Details
- Series:UPV
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:120 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:-
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:-
- Ripple Current @ High Frequency:-
- Impedance:340 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.512" (13.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
