860240575008
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP 220 UF 20% 35 V
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 590
Can ship immediately
Pricing:
- 1$0.64
- 500$0.39854
- 1,000$0.38054
Quote It
Technical Details
- Series:WCAP-AT1H
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:380 mA @ 120 Hz
- Ripple Current @ High Frequency:760 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.846" (21.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
