UHD1H151MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 150UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHD1H151MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 340
Can ship immediately
Pricing:
- 1$0.67
- 500$0.2114
- 1,000$0.17969
- 2,500$0.16912
- 5,000$0.15855
- 12,500$0.14534
- 25,000$0.1427
- 50,000$0.13741
Quote It
Technical Details
- Series:UHD
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:150 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:4000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:685.3 mA @ 120 Hz
- Ripple Current @ High Frequency:979 mA @ 100 kHz
- Impedance:61 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
