ELXZ630ETD101MJC5S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 63V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet ELXZ630ETD101MJC5S Datasheet
-
ECAD Model
- Share
In Stock: 730
Can ship immediately
Pricing:
- 1$0.74
- 800$0.16697
- 1,600$0.15769
- 2,400$0.14842
- 4,000$0.13914
- 8,000$0.12986
- 20,000$0.12755
- 40,000$0.12523
- 80,000$0.12059
Quote It
Technical Details
- Series:LXZ
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:216 mA @ 120 Hz
- Ripple Current @ High Frequency:540 mA @ 100 kHz
- Impedance:255 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
