UPJ1J121MHD6TO
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 120UF 20% 63V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPJ1J121MHD6TO Datasheet
-
ECAD Model
- Share
In Stock: 971
Can ship immediately
Pricing:
- 1$0.79
- 500$0.26498
- 1,000$0.22314
- 2,500$0.20919
- 5,000$0.19525
- 12,500$0.18548
- 25,000$0.1813
- 50,000$0.17781
Quote It
Technical Details
- Series:UPJ
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:120 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:510 mA @ 120 Hz
- Ripple Current @ High Frequency:750 mA @ 10 kHz
- Impedance:180 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.650" (16.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
