EEU-FS1C122LB
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1200UF 20% 16V T/H
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FS1C122LB Datasheet
-
ECAD Model
- Share
In Stock: 918
Can ship immediately
Pricing:
- 1$0.81
- 1,000$0.21674
- 2,000$0.20399
- 5,000$0.19124
- 10,000$0.17849
- 25,000$0.17212
- 50,000$0.16574
Quote It
Technical Details
- Series:FS
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:1200 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:9000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.248 A @ 120 Hz
- Ripple Current @ High Frequency:1.56 A @ 100 kHz
- Impedance:30 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
