EEU-FR1H271B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 270UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FR1H271B Datasheet
-
ECAD Model
- Share
In Stock: 546
Can ship immediately
Pricing:
- 1$0.88
- 500$0.32028
- 1,000$0.2697
- 2,500$0.25284
- 5,000$0.23599
- 12,500$0.22419
- 25,000$0.21913
Quote It
Technical Details
- Series:FR
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:270 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.323 A @ 120 Hz
- Ripple Current @ High Frequency:1.89 A @ 100 kHz
- Impedance:23 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
