UWD1H101MCL1GS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 50V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UWD1H101MCL1GS Datasheet
-
ECAD Model
- Share
In Stock: 244
Can ship immediately
Pricing:
- 1$0.91
- 500$0.34718
- 1,000$0.29896
- 2,500$0.27967
- 5,000$0.26521
- 12,500$0.26231
Quote It
Technical Details
- Series:UWD
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:-
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:150 mA @ 120 Hz
- Ripple Current @ High Frequency:300 mA @ 100 kHz
- Impedance:340 mOhms
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.413" (10.50mm)
- Surface Mount Land Size:0.327" L x 0.327" W (8.30mm x 8.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
