EEE-FN1J100V

Technical Details

• Series:FN, Anti-Vibration
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Capacitance:10 µF
• Tolerance:±20%
• Voltage - Rated:63 V
• ESR (Equivalent Series Resistance):1.5Ohm @ 100kHz
• Lifetime @ Temp.:2000 Hrs @ 105°C
• Operating Temperature:-55°C ~ 105°C
• Polarization:Polar
• Ratings:AEC-Q200

• Applications:Automotive
• Ripple Current @ Low Frequency:52 mA @ 120 Hz
• Ripple Current @ High Frequency:80 mA @ 100 kHz
• Impedance:-
• Lead Spacing:-
• Size / Dimension:0.248" Dia (6.30mm)
• Height - Seated (Max):0.252" (6.40mm)
• Surface Mount Land Size:0.260" L x 0.260" W (6.60mm x 6.60mm)
• Mounting Type:Surface Mount
• Package / Case:Radial, Can - SMD
