UWG1C681MNL1GS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 680UF 20% 16V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UWG1C681MNL1GS Datasheet
-
ECAD Model
- Share
In Stock: 495
Can ship immediately
Pricing:
- 1$0.93
- 500$0.3384
- 1,000$0.28496
- 2,500$0.26715
- 5,000$0.24934
- 12,500$0.23687
- 25,000$0.23153
Quote It
Technical Details
- Series:UWG
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:680 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:-
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:335 mA @ 120 Hz
- Ripple Current @ High Frequency:670 mA @ 100 kHz
- Impedance:150 mOhms
- Lead Spacing:-
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.394" (10.00mm)
- Surface Mount Land Size:0.406" L x 0.406" W (10.30mm x 10.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
