UWH1A101MCL1GS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 10V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UWH1A101MCL1GS Datasheet
-
ECAD Model
- Share
In Stock: 788
Can ship immediately
Pricing:
- 1$0.94
- 1,000$0.28931
- 2,000$0.27123
- 5,000$0.25315
- 10,000$0.2441
- 25,000$0.23506
Quote It
Technical Details
- Series:UWH
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:-
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:58 mA @ 120 Hz
- Ripple Current @ High Frequency:87 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.244" (6.20mm)
- Surface Mount Land Size:0.327" L x 0.327" W (8.30mm x 8.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
