EEE-FKC271XSV

Technical Details

• Series:FKS, Anti-Vibration
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Capacitance:270 µF
• Tolerance:±20%
• Voltage - Rated:16 V
• ESR (Equivalent Series Resistance):340mOhm @ 100kHz
• Lifetime @ Temp.:2000 Hrs @ 105°C
• Operating Temperature:-55°C ~ 105°C
• Polarization:Polar
• Ratings:AEC-Q200

• Applications:Automotive, High Temperature Reflow
• Ripple Current @ Low Frequency:182 mA @ 120 Hz
• Ripple Current @ High Frequency:280 mA @ 100 kHz
• Impedance:-
• Lead Spacing:-
• Size / Dimension:0.248" Dia (6.30mm)
• Height - Seated (Max):0.327" (8.30mm)
• Surface Mount Land Size:0.260" L x 0.260" W (6.60mm x 6.60mm)
• Mounting Type:Surface Mount
• Package / Case:Radial, Can - SMD
