UBW1K220MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 22UF 20% 80V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UBW1K220MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 911
Can ship immediately
Pricing:
- 1$1.15
- 1,000$0.41227
- 2,000$0.38479
- 5,000$0.37105
- 10,000$0.3573
- 25,000$0.34357
Quote It
Technical Details
- Series:UBW
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:22 µF
- Tolerance:±20%
- Voltage - Rated:80 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 135°C
- Operating Temperature:-55°C ~ 135°C
- Polarization:Polar
- Ratings:-
- Applications:Automotive
- Ripple Current @ Low Frequency:75 mA @ 120 Hz
- Ripple Current @ High Frequency:150 mA @ 100 kHz
- Impedance:1.5 Ohms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.531" (13.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
