UFG1H331MHM1TO
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 330UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UFG1H331MHM1TO Datasheet
-
ECAD Model
- Share
In Stock: 517
Can ship immediately
Pricing:
- 1$1.17
- 500$0.4464
- 1,000$0.3844
- 2,500$0.3596
- 5,000$0.341
- 12,500$0.32314
- 25,000$0.3162
Quote It
Technical Details
- Series:UFG
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:330 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:Audio
- Ripple Current @ Low Frequency:488 mA @ 120 Hz
- Ripple Current @ High Frequency:-
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
