EMZJ6R3ADA102MHA0G
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1000UF 20% 6.3V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EMZJ6R3ADA102MHA0G Datasheet
-
ECAD Model
- Share
In Stock: 225
Can ship immediately
Pricing:
- 1$1.19
- 500$0.38984
- 1,000$0.33569
- 2,500$0.31405
- 5,000$0.2978
- 12,500$0.28221
- 25,000$0.28053
Quote It
Technical Details
- Series:Alchip™- MZJ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):80mOhm @ 100kHz
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:510 mA @ 120 Hz
- Ripple Current @ High Frequency:850 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.406" (10.30mm)
- Surface Mount Land Size:0.327" L x 0.327" W (8.30mm x 8.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
