860080478022
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1500UF 20% 25V T/H
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 188
Can ship immediately
Pricing:
- 1$1.22
- 300$0.85423
- 600$0.75323
- 1,500$0.72023
Quote It
Technical Details
- Series:WCAP-ATLI
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:1500 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:-
- Ripple Current @ High Frequency:2.71 A @ 100 kHz
- Impedance:23 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.512" Dia (13.00mm)
- Height - Seated (Max):1.043" (26.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
