UBW1E221MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UBW1E221MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 432
Can ship immediately
Pricing:
- 1$1.26
- 500$0.51408
- 1,000$0.4536
- 2,500$0.42336
- 5,000$0.41126
Quote It
Technical Details
- Series:UBW
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 135°C
- Operating Temperature:-55°C ~ 135°C
- Polarization:Polar
- Ratings:-
- Applications:Automotive
- Ripple Current @ Low Frequency:340 mA @ 120 Hz
- Ripple Current @ High Frequency:680 mA @ 100 kHz
- Impedance:100 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.571" (14.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
