UBX1V101MPL1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UBX1V101MPL1TD Datasheet
-
ECAD Model
- Share
In Stock: 624
Can ship immediately
Pricing:
- 1$1.29
- 500$0.52514
- 1,000$0.46335
- 2,500$0.43246
- 5,000$0.41702
- 12,500$0.39385
- 25,000$0.38613
Quote It
Technical Details
- Series:UBX
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 150°C
- Operating Temperature:-55°C ~ 150°C
- Polarization:Polar
- Ratings:-
- Applications:Automotive
- Ripple Current @ Low Frequency:200 mA @ 120 Hz
- Ripple Current @ High Frequency:400 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.846" (21.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
