URS0J682MHD1TN
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 6800UF 20% 6.3V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet URS0J682MHD1TN Datasheet
-
ECAD Model
- Share
In Stock: 348
Can ship immediately
Pricing:
- 1$1.3
- 250$0.62232
- 500$0.52897
- 750$0.49786
- 1,250$0.46674
- 2,500$0.43563
- 6,250$0.42007
- 12,500$0.39673
- 25,000$0.38895
Quote It
Technical Details
- Series:URS
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:6800 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.66 A @ 120 Hz
- Ripple Current @ High Frequency:1.909 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.650" (16.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
