EKZN101ELL101MJ20S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EKZN101ELL101MJ20S Datasheet
-
ECAD Model
- Share
In Stock: 149
Can ship immediately
Pricing:
- 1$1.14
- 10$0.85289
- 100$0.60322
- 500$0.48938
- 1,000$0.4211
- 2,500$0.39834
- 5,000$0.37556
Quote It
Technical Details
- Series:KZN
- Package:Bulk
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:572 mA @ 120 Hz
- Ripple Current @ High Frequency:1.43 A @ 100 kHz
- Impedance:68 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.846" (21.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
