EEV-EB2D220SQ
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 22UF 20% 200V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEV-EB2D220SQ Datasheet
-
ECAD Model
- Share
In Stock: 131
Can ship immediately
Pricing:
- 1$2.43
- 150$1.36317
- 300$1.16841
- 750$0.97367
- 1,050$0.90876
- 3,750$0.8763
- 7,500$0.84385
Quote It
Technical Details
- Series:EB
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:22 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:258.5 mA @ 120 Hz
- Ripple Current @ High Frequency:470 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.669" (17.00mm)
- Surface Mount Land Size:0.531" L x 0.531" W (13.50mm x 13.50mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
