EEV-TG1H102M
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1000UF 20% 50V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEV-TG1H102M Datasheet
-
ECAD Model
- Share
In Stock: 189
Can ship immediately
Pricing:
- 1$2.98
- 125$1.67148
- 250$1.43266
- 625$1.27347
- 875$1.19389
- 1,250$1.11429
- 3,125$1.08245
Quote It
Technical Details
- Series:TG
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):140mOhm @ 100kHz
- Lifetime @ Temp.:2000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:617.5 mA @ 120 Hz
- Ripple Current @ High Frequency:950 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.650" (16.50mm)
- Surface Mount Land Size:0.748" L x 0.748" W (19.00mm x 19.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
