EEU-EE2W470S
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 47UF 20% 450V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-EE2W470S Datasheet
-
ECAD Model
- Share
In Stock: 103
Can ship immediately
Pricing:
- 1$2.51
- 10$2.02873
- 100$1.54917
- 500$1.1803
- 1,000$1.03276
- 2,500$1.00325
Quote It
Technical Details
- Series:EE
- Package:Bulk
- Part Status:Active
- Capacitance:47 µF
- Tolerance:±20%
- Voltage - Rated:450 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:420 mA @ 120 Hz
- Ripple Current @ High Frequency:1.2 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
