UFW1E102MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1000UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UFW1E102MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 120
Can ship immediately
Pricing:
- 1$0.72
- 500$0.26012
- 1,000$0.21905
- 2,500$0.20536
- 5,000$0.19167
- 12,500$0.18209
- 25,000$0.17798
- 50,000$0.17455
Quote It
Technical Details
- Series:UFW
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:Audio
- Ripple Current @ Low Frequency:950 mA @ 120 Hz
- Ripple Current @ High Frequency:1.0925 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
